Product Details:
|
| Input Voltage: | 110v 220v | Output Voltage: | 24V |
|---|---|---|---|
| Output Frequency: | 50/60Hz | Output Current: | 15A |
| Application: | LED Lighting Or CCTV Cameras | Warranty: | 5 Years |
| Type: | Constant Voltage | Protection: | Overvoltage Overload Short Circuit Overtemperature |
| PAYMENT: | T/T | Test: | 100%Full Load Burn-in Test |
| Output | 12V 30A | 24V 15A |
| AC input voltage range | 110-264VAC | |
| Input current | 0.5A/115V 0.25A/230V | |
| AC impulse current | Cold-start current 13A/115V 26A/230V | |
| DC output voltage | 12V | 24V |
| DC output power | 360W | 360W |
| Rated output current | 30A | 15A |
| Output voltage error | ±1% | ±1% |
| Efficiency | 85% | 85% |
| Wave and noise | 100mVp-p | 100mVp-p |
| Inlet stability | ±0.5% | ±0.5% |
| Load stability | ±0.5% | ±0.5% |
| Leakage current | <0.5mA/240VAC | |
| Overload protection | 105% - 150% rated power, automatically recovery | |
| Vibration | 10500Hz,2G 10min./1cycle,Period for 60min,Each axes | |
| Cooling method | Natural cooling air convection | |
| Working temperature and humidity | - 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost) | |
| Store temperature and humidity | - 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost) | |
| Safety standards | CE(EMC+LVD),Rohs | |
Standard export package (paper carton) for shipment, or package as you need..
1,How many voltage can you supply?
-- 5V, 6.5V,9V 10V,12V, 13.5V, 15V, 18V, 19V, 24V 36V, 48V (depend on items)
2,How many current can you supply?
-- 0.5A, 1A,1.25A, 1.5A, 2A, 2.5A,3A, 3.42A,4A, 5A, 6A, 10A, 15A 20A, 30A, 40A, 50A, 60A
4,How's your power supply and adapter quality?
-- 100% burn-in test, full-round tests. We promise less than 1% defetive within one year.If within 1% defetive, just show us inner unique serial number of defetive products and we can replace for free in the next order;
