Product Details:
|
| Output Type: | Single | Input Voltage: | 100~240v Ac |
|---|---|---|---|
| Output Voltage: | 12V | Output Frequency: | 50/60Hz |
| Output Current: | 3A | Application: | Access Control |
| Product Name: | Power Supply Control | Warranty: | 5 Years |
| Type: | Constant Voltage Mode Power | Protection: | Short Circuit |
| Efficiency: | 82% | Size: | 104x68x33mm |
| Protections: | Shortcuit Overtemp Overload Overtemp | Name: | Power Supply Control 12v 3a |
system and related applications such as Electric Magnetic lock , lock controller, RFID-IC card reader ,password keypad etc.
The power supply is one part of access control system.
Product Description
1.Small and exquisite, easy installation.
2.Advantages: Voltage range input regularly from 100V-240V, compatible with world voltage, light weight, convenient transportation, small disturbance, output voltage fluctuation is only ±1% from no-load to full load, lock temperature rising reduces greatly (compared with power frequency supply).
3.AC input: Standard AC100V-240V 50-60HZ 36W
4.DC output: Stabilizator DC12V/ 3 A
5.It controls electric lock directly. It can set time lapse control circuit and unlocking time can be in 0-15 seconds(it is arbitrarily adjustable).
6.Automatic protection function: It will protect automatical and no voltage output when short circuit happening in the circumferential circuit.
7.Outside iron shell dimension:120mm*95 mm*38mm
8.Set NC/NO outputs, can control various types of electric locks
9.Note: Opening time must set to 0 second when connecting with electric controlled lock. Otherwise electric bolt lock would be Burned Down.
