Product Details:
|
| Output Type: | AC | Connection: | Plug In |
|---|---|---|---|
| Certificate: | CE | Product Name: | Laptop Ac Adapter |
| Output Voltage: | 24v Ac | Color: | Black |
| Usage: | PTZ Camera | Warranty: | 2 Years |
| Type: | Wall Plug | Output Current: | 1-3A |
| Name: | 24V Ac Adapter | Input Voltage: | AC110V/220v |
| Port: | Shenzhen |
Protections: Short circuit / Overload / Over voltage / Over temperature
-- 100% full load burn-in test
-- Low cost, high reliability
-- 2 years warranty
| Input | Input connecting plug | USA/EUR/UK/AU/others, 70cm/others |
| Input voltage | AC110V/120V/220V/230V, 50/60Hz | |
| Output | Output connector | 5.5 * 2.1mm/others, 90cm/others |
| Max power | AC/DC 3-24V (+ / - 5%) | |
| Output voltage | 15W(12V 1A) | |
| Ripple wave | (mVp-p): <1% | |
| Temperature coefficient | ±0.02%/℃ | |
| Start time | ≤3s(240VAC input,io=100%) | |
| Guard time | ≥20ms(240VAC input,io=100%) | |
| Output standard | AC,DC 12V 1A | |
| Temperaturer | Working temperature | 0℃-40℃,10%-90%RH |
| Store temperature | -20℃-60℃,10%-90%RH | |
| Size | Size | 86*60*43mm |
| Net weight | 431g |
1,Promotely reponse and fast production leadtime 2,Best pre-sale & after-sale service
3,Reliable products quality and good reputation 4,High manufacturing capacity
5.OEM/ODM
1,How many voltage can you supply?
-- 5V, 6.5V,9V 10V,12V, 13.5V, 15V, 18V, 19V, 24V 36V, 48V (depend on items)
2,How many current can you supply?
-- 0.5A, 1A,1.25A, 1.5A, 2A, 2.5A,3A, 3.42A,4A, 5A, 6A, 10A, 15A 20A, 30A, 40A, 50A, 60A
3,How about the quality?
-- We have the best professional and experienced engineer and strict QA and QC system. Repair rate under 1.1%-0.2%
4,Can we be your distributor?
-- We are looking for distributor and agent all over the world for switching power supply. Should you any interest, please feel free to send your message or inquiry.
5,What’s kind of payment you accept?
-- T/T, L/C, Paypal, Western Union,ect
6,What’s your MOQ?
-- 3000pcs, except for sample order or trial order.
Contact Person: Mr. Zhang
Tel: +8617337136440
