Product Details:
|
| Output Type: | DC | Connection: | Plug In |
|---|---|---|---|
| Certificate: | CE | Output: | 12V 2A |
| Product Name: | Rainproof Power Supply | Output Voltage: | 12VDC |
| Color: | Black | Warranty: | 3 Years |
| Output Current: | 2000mA | Type: | AU Wall Mount |
| Name: | 12V 2a Rainproof Power Adapter | Brand: | C-Power |
Feature
100% Brand New
Length of the cable: 120CM
Input:100V-240V AC 50/60Hz 0.3A
Output:12V DC 2A
Protections: Short circuit/Overload/Overvoltage
100% full loading burn-in test
3 years warranty
Specification:
| Oupt power range | 12V 2A |
| Input Rated Voltage | 100Vac~240Vac |
| Input Frequency Range | 47Hz~63Hz |
| Input Current | less than 0.5A |
| Input Inrush Current | less than 50A |
| Efficiency | 80%(MIN)at Rated Voltage |
| DC Output Voltage | 12V± 5% |
| DC Output Current | 2A |
| DC Output Power | 24W |
| Leakage Current | less than 1mA |
| Standby power | less than 0.5w |
| DC connector | 5.5*2.1*10mm/5.5*2.5 *10mm(optional) |
| DC cable | 1.2m cable (optional) |
| Ripple and Noise | less than 120Mv at full road with 20MHz bandwidth |
| Turn On Delay Time | less than 3S (AC:110V and full load) |
| Dielectric Voltage | A IEC320 three pin input---output(FG)3000Vac one minute |
| Safety protection | output voltage protection (150%-180% rated output current) |
|
| output current protection (150%-180% rated output current) |
|
| short current protection |
| Operating Temperature | 0°C - +55°C |
| Storage Temperature | -20°C - +85°C |
