Product Details:
|
| Output Type: | Single | Input Voltage: | 110v/220v, 220V |
|---|---|---|---|
| Output Voltage: | 12V | Output Frequency: | 50/60Hz |
| Output Current: | 10A | Application: | CCTV Camera |
| Warranty: | 3 Years | Product Name: | 12v Multiple Output Power Supply |
| Type: | Constant Voltage | Efficiency: | 82% |
| Name: | Power Supply Box 10a 9ch | Brand: | C-Power |
| Power: | 120w |
9 Channel 10A 120W
Powering multiple cameras could not be easier!
Our line of Professional Power Supplies give installers what they expect when it comes to power supplies, reliability.
Every channel is protected with Auto-Reset PTC fuses, which means these fuses will not blow.
This box can be mounted to any surface, plugged into an AC outlet, and up in seconds!
Output:
DC Output Voltage: 12V
Output Voltage Tolerance: ± 1%
Rated Output Current: 10A
Output Current Range: 0-10A
Output Power: 120W
Ripple and Noise: 100mVp-p
DC Voltage Adjustable Range: ± 10%
Input:
Input Voltage Range: 90-130V, 47~63Hz
AC Input Current: 0.65A/115V
Efficiency: 95%
Working Temperature and Humidity: -20~+40℃, 20%-93%RH
Storage Temperature and Humidity: -20~+55℃, 10%-95%RH
12V DC - 10amp Supply Current
Multiple Outputs (9 channel)
Every channel is protected with Auto-Reset PTC fuses
Power on/off switch
DC regulated, over current and voltage protected
Individual LED indicator for each out put
Support up to 9 Cameras
Metal case with lock
1,Promotely reponse and fast production leadtime 2,Best pre-sale & after-sale service
3,Reliable products quality and good reputation 4,High manufacturing capacity
5.OEM/ODM
