Product Details:
|
| Output Type: | DC | Connection: | Plug In |
|---|---|---|---|
| Output: | 48V 0.5A | Color: | Black |
| Certificate: | Ce | Warranty: | 3 Years |
| Input: | AC 100-240v 50-60hz | Type: | Constant Voltage |
| Output Current: | 0.5A | Application: | LED Light. Electrical Appliances |
| DC Cable: | 1.8m | DC Jack (plug): | 5.5*2.1*10/5.5*2.5*10mm / Customerized |
Specifications:
| Output | 48V DC 500mA |
| Input | 100-240V 50/60HZ |
| Output | 48V-0.5A |
| Input Current | 1A |
| Efficiency | 80% Min |
| Line / Load Regulation | 3% / 5% |
| Ripple / Noise | 200mV p-p |
| Turn-On Delay | 2 Seconds Max |
| Rise Time | 40 mS Max |
| Protections | Auto Recover Over-Voltage, Short Circuit, Over-Current |
| Safety and EMC Standards | UL 60950, CE |
| Environmental Standards | RoHs |
| Operating Temperature | -10 to +40°C (14 to +104°F) |
| Operating Humidity (RH) | 5% - 90% |
| Storage Temperature | -20 to +85°C (-4 to +185°F) |
| Network Connector Type | RJ45 Shielded |
| POE Type | Passive POE ( Pins 4,5 V+, Pins 7,8 V-) |
1,Promotely reponse and fast production leadtime 2,Best pre-sale & after-sale service
3,Reliable products quality and good reputation 4,High manufacturing capacity
5.OEM/ODM
