Product Details:
|
| Type: | Plug-In Charger | Material: | PC Fireproof Material, ABS, Aluminium Alloy |
|---|---|---|---|
| Protection: | Short Circuit Protection, Ovp, OTP | Function: | QC2.0 |
| Color: | Black, Black | Input Voltage And Current: | 110v/220v |
| Output Voltage And Current: | 72v | Usage: | E-motorcycles |
| Keywords: | Charger Adaptor | Application: | Electric Motorcycle |
| Warranty: | 2 Years | Product Name: | Battery Charger |
| Condition: | BRAND NEW | Output Type: | DC |
| Connection: | Plug In | Use: | Electric Car, Electr Bike, Scooter |
| Is LED Lamp Illumination: | Yes |
Input Voltage: 110v/220v
Output Voltage Optional:
84V 15a (For 23 series 72V Li-ion Lithium Polymer Battery use)
87.6V 15a (For 24 series 72V Li-ion Lithium Polymer Battery use)
90AH~100AH
Output Current: 15a
Charging Mode: CC-CV
Intelligent Charger
Aluminium Case-good heat sinking
Super Cooling Fan
Features:
1. Advanced high frequency switching mode power supply technology
2. DC output isolated from AC input
3. Single input 110V AC and 220V AC 50-60Hz
4. Charging parameters are insensitive to the AC input line voltage variations
5. Completely automatic battery charging: CC, CV
6. 2 LEDs: LED 1 Red (power on), LED2 Red/Green (Charging/Full)
7. Short circuit, over voltage, over-temperature, reverse polarity protections
8. Efficiency > 85%
9. Forced ventilation with fans
10. 100% full load burn-in test.
