Product Details:
|
| Type: | Electric, Plug-In Charger | Material: | PC Fireproof Material, ABS, Aluminium Alloy |
|---|---|---|---|
| Protection: | Short Circuit Protection, Ovp, OTP | Function: | QC2.0 |
| Port: | DC, AC | Input Voltage And Current: | 110v/220v |
| Output Voltage And Current: | 48v | Maximum Output Power: | 135W |
| Warranty: | 2 Years | Color: | Black |
| Application: | Electric Motorcycle | Keywords: | Charger Adaptor |
| Output Voltage: | 48V/60V/72V | Condition: | BRAND NEW |
| Connection: | Plug In | Is LED Lamp Illumination: | Yes |
Input Voltage: 110v/220v
Output Voltage Optional:
54.6V 20a (For 13 series 48V Li-ion Lithium Polymer Battery use)
58.8V 20a (For 14 series 48V Li-ion Lithium Polymer Battery use)
54.75V 20a (For 15 series 48V Li-ion Lithium Polymer Battery use)
58.4V 20a (For 16 series 48V Li-ion Lithium Polymer Battery use)
Output Current: 20a
Charging Mode: CC-CV
Intelligent Charger
Aluminium Case-good heat sinking
Super Cooling Fan
Features:
1. Advanced high frequency switching mode power supply technology
2. DC output isolated from AC input
3. Single input 110V AC and 220V AC 50-60Hz
4. Charging parameters are insensitive to the AC input line voltage variations
5. Completely automatic battery charging: CC, CV
6. 2 LEDs: LED 1 Red (power on), LED2 Red/Green (Charging/Full)
7. Short circuit, over voltage, over-temperature, reverse polarity protections
8. Efficiency > 85%
9. Forced ventilation with fans
10. 100% full load burn-in test.
