Product Details:
|
| Output Power: | 101 - 200W | Output Type: | Single |
|---|---|---|---|
| Input Voltage: | 110V/220V | Output Voltage: | 12V DC |
| Output Frequency: | 50/60HZ | Output Current: | 10A |
| Efficiency: | 82% | Product Name: | Swtiching Power Supply Box |
| Protections: | Short Circuit Overload Overvolt Overtemp | Warranty: | 3 Years |
| Application: | CCTV Camera | Type: | Constant Voltage |
| Channels: | 9ch | Input: | 110/220v |
| Color: | Grey |
Input Voltage : AC 100-240V Input Voltage Frequency : 50/60Hz Output Voltage : DC 12V +/-5% Total Output Current : 10A Total Outputs : 9 Fuse Type : PTC (Resetable) Fuse Rating : 1.1A
| Input | Input voltage | AC100-240V, 50/60Hz |
| Output | Output connector | 9Channel |
| Max power | 120W | |
| Output voltage | DC 12V + / - 5% | |
| Ripple wave | (mVp-p): <1% | |
| Linear modulate | ±0.5%max | |
| Temperature coefficient | ±0.02%/℃ | |
| Start time | ≤3s(240VAC input,io=100%) | |
| Guard time | ≥20ms(240VAC input,io=100%) | |
| Output standard | 12V10A,9channel Output | |
| Protection | Override protection | 115%-200%vA,automatic recovery |
| short-circuit protection | 1 channel: automatic recovery | |
| Insulation | Insulation strength | 1500VAC/10mA,1MIN |
| Insulation resistance | ≥30MΩ,DC 500V | |
| Environment | Working temperature | 0℃-40℃,10%-90%RH |
| Store temperature | -20℃-60℃,10%-90%RH | |
| Size | Size | 302*202*50mm |
| Net Net weight | 1623g |
1,Promotely reponse and fast production leadtime 2,Best pre-sale & after-sale service
3,Reliable products quality and good reputation 4,High manufacturing capacity
5.OEM/ODM
