Product Details:
Place of Origin: China
Brand Name: C-Power
Model Number: CP-PSU18CH/30A
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $16.75/pieces >=10 pieces
Packaging Details: Packaging Details: Color package , 10PCS/CTN ,Size :54*26*43.5CM
Supply Ability: 100000 Piece/Pieces per Month

360W 18channels Switching Power Supply dc12v 30A 220V 110V AC Protection Over-voltage

Description
Output Type: Multiple Input Voltage: 220V / 110V
Output Voltage: 12V Output Frequency: 50/60Hz
Output Current: 30A Application: Led Strip
Warranty: 3 Years Protection: Over-voltage
Name: CCTV / LED Power Supply For CCTV Camera Or Led Light Price: Factory Selling

Product Description

 12v 30A PSU , 220V / 110V AC to 12V DC 360W LED Switch Power Supply for LED Light  / LED Stripe



Product Description:

Input Voltage : AC110V  /  220V  Input Voltage  Frequency : 50/60Hz Output Voltage : DC 12V +/-5% Total Output Current : 30A Total Outputs : 18 Fuse Type : PTC (Resetable) Fuse Rating : 1.1A



Input Input voltage AC100-240V, 50/60Hz
Output Output connector 18 channel
Max power 360W
Output voltage DC 12V + / - 5%
Ripple wave (mVp-p): <1%
Linear modulate ±0.5%max
Temperature coefficient ±0.02%/
Start time 3s(240VAC input,io=100%)
Guard time 20ms(240VAC input,io=100%)
Output standard 12V30A,18 channel Output
Protection Override protection 115%-200%vA,automatic recovery
short-circuit protection 1 channel: automatic recovery
Insulation Insulation strength 1500VAC/10mA,1MIN
Insulation resistance 30MΩ,DC 500V
Environment Working temperature 0-40,10%-90%RH
Store temperature -20-60,10%-90%RH
Size Size 302*202*61mm
Net Net weight 2130g

 360W 18channels Switching Power Supply dc12v 30A 220V 110V AC Protection Over-voltage 0

Our Services

 360W 18channels Switching Power Supply dc12v 30A 220V 110V AC Protection Over-voltage 1



1,Promotely reponse and fast production leadtime     2,Best pre-sale & after-sale service

3,Reliable products quality and good reputation         4,High manufacturing capacity

FAQ

 360W 18channels Switching Power Supply dc12v 30A 220V 110V AC Protection Over-voltage 2

1,How many voltage can you supply?

-- 5V, 6.5V,9V 10V,12V, 13.5V, 15V, 18V, 19V, 24V 36V, 48V (depend on items)

2,How many current can you supply?

-- 0.5A, 1A,1.25A, 1.5A, 2A, 2.5A,3A, 3.42A,4A, 5A, 6A, 10A, 15A 20A, 30A, 40A, 50A, 60A

3,How about the quality?

-- We have the best professional and experienced engineer and strict QA and QC system. Repair rate under 1.1%-0.2%

4,Can we be your distributor?

-- We are looking for distributor and agent all over the world for switching power supply. Should you any interest, please feel free to send your message or inquiry.

5,Whats kind of payment you accept?

-- T/T, L/C, Paypal, Western Union,ect

6,Whats your MOQ?

-- 3000pcs, except for sample order or trial order.
