Product Details:
Place of Origin: Guangdong, China
Brand Name: C-Power
Model Number: CP-PSU3A/4CH
Payment & Shipping Terms:
Minimum Order Quantity: 16 pieces
Price: $8.99/pieces >=16 pieces
Packaging Details: Color package , 16PCS/CTN ,Size :54*26*43.5CM
Supply Ability: 100000 Piece/Pieces per Month

12V DC 3A 4CH CCTV Camera Power Supply Box with Customizable Output Channels

Description
Output Type: Multiple Input Voltage: 110v 220v
Output Voltage: 12V Output Frequency: 50/60Hz
Output Current: 3A Application: CCTV Camera
Product Name: CCTV Mental Box Power Supply Warranty: 2 Years
Protection: 4 Fuse Type Price: Factory Selling
Payment: T/T, Paypal,Western Union,ect Service: OEM ODM
Style: Switching Power Supply

Product Description

 DC 12V 3A 4CH CCTV CAMERA POWER SUPPLY BOX for CCTV Camera



Product Description:

Input Voltage : AC 100-240V Input Voltage Frequency : 50/60Hz Output Voltage : DC 12V +/-5% Total Output Current : 3A Total Outputs : 4 Fuse Type : PTC (Resetable) Fuse Rating : 1.1A



Input Input voltage AC100-240V, 50/60Hz
Output Output connector 4 channel
Max power 38W
Output voltage DC 12V + / - 5%
Ripple wave (mVp-p): <1%
Linear modulate ±0.5%max
Temperature coefficient ±0.02%/
Start time 3s(240VAC input,io=100%)
Guard time 20ms(240VAC input,io=100%)
Output standard 12V3.2A,4 channelOutput
Protection Override protection 115%-200%vA,automatic recovery
short-circuit protection 1 channel: automatic recovery
Insulation Insulation strength 1500VAC/10mA,1MIN
Insulation resistance 30MΩ,DC 500V
Environment Working temperature 0-40,10%-90%RH
Store temperature -20-60,10%-90%RH
Size Size 190*173*53mm
Net Net weight 1000g



 12V DC 3A 4CH CCTV Camera Power Supply Box with Customizable Output Channels 0



Our Services



12V DC 3A 4CH CCTV Camera Power Supply Box with Customizable Output Channels 1



1,Promotely reponse and fast production leadtime     2,Best pre-sale & after-sale service

3,Reliable products quality and good reputation         4,High manufacturing capacity

FAQ

 12V DC 3A 4CH CCTV Camera Power Supply Box with Customizable Output Channels 2

1,How many voltage can you supply?

-- 5V, 6.5V,9V 10V,12V, 13.5V, 15V, 18V, 19V, 24V 36V, 48V (depend on items)

2,How many current can you supply?

-- 0.5A, 1A,1.25A, 1.5A, 2A, 2.5A,3A, 3.42A,4A, 5A, 6A, 10A, 15A 20A, 30A, 40A, 50A, 60A

3,How about the quality?

-- We have the best professional and experienced engineer and strict QA and QC system. Repair rate under 1.1%-0.2%

4,Can we be your distributor?

-- We are looking for distributor and agent all over the world for switching power supply. Should you any interest, please feel free to send your message or inquiry.

5,Whats kind of payment you accept?

-- T/T, L/C, Paypal, Western Union,ect

6,Whats your MOQ?

-- 3000pcs, except for sample order or trial order.
